Vigor2926Vac

Dual-WAN Load Balancing VPN Router

The Equipment That Does It All

Vigor2926 series is a Dual-Ethernet WAN router featuring VPN, SSL VPN, advanced routing rules, firewall, content filtering, bandwidth management and lots more, providing SMBs an integrated solution to build a reliable and secure business network. Models with built-in 802.11ac Wave 2 Wi-Fi and VoIP Gateway are available.

Up to 4 WAN

load balancing. NAT throughput up to 500 Mbps

50 VPN

IPsec VPN throughput up to 80 Mbps

25 SSL VPN

Throughput up to 45 Mbps

50k Sessions

Recommended for a network of 50 hosts

Load Balancing

Maximize throughput and reliability by using multiple Internet connections.

Bandwidth Management

Prevent one device using all the bandwidth by bandwidth limit policy, session limit policy, and QoS settings.

VPN (Virtual Private Network)

Build a secure and private tunnel from the LAN of Vigor2926 Series to the remote offices and teleworkers over the Internet.

QoS for VoIP

Give first priority to VoIP traffic to improve your call quality, and monitor VoIP statistics from the router.

Hotspot Web Portal

Market your business and communicate with the guests while offering hospitality Wi-Fi.

Wireless WAN

Get Internet access wirelessly from a Wi-Fi network, a mobile hotspot, or a personal hotspot set up on smartphones.

Firewall & Content Filter

Filter web pages by URL keyword or web category to block access to insecure or inappropriate contents.

Central AP Management

Use the Vigor2926 Series router as a wireless controller to maintain and monitor the VigorAPs.

SSL VPN

The VPN works through firewalls providing secure remote access to any network environment.

DrayDDNS

The free DDNS service for you to access the router by a fixed hostname of your choice.

Central Switch Management

Set up VLAN easily from the router and get a centralized hierarchy view of the switches.

Interface
Fixed WAN Port 1x Gigabit Ethernet
LAN/WAN Switchable Port 1x Gigabit Ethernet
Fixed LAN Port 4x Gigabit Ethernet
USB Port 2x USB 2.0 for 3G/4G/LTE USB modem, storage, printer or thermometer
5G WLAN 802.11ac Wave 2 4x4 MIMO 1.7Gbps
Performance
NAT Throughput 500 Mbps
NAT Throughput w/ Hardware Acceleration 900 Mbps
IPsec VPN Performance 80 Mbps (AES 256 bits)
SSL VPN Performance 45 Mbps
Max. Number of NAT Sessions 50,000
Max. Concurrent VPN Tunnels 50
Max. Concurrent OpenVPN + SSL VPN 25
Internet Connection
IPv4 PPPoE, DHCP, Static IP, PPTP/L2TP
IPv6 PPP, DHCPv6, Static IPv6, TSPC, AICCU, 6rd, 6in4 Static Tunnel
802.1p/q Multi-VLAN Tagging
Multi-VLAN/PVC
Wireless WAN
3G/4G/LTE WAN with USB modem
Load Balancing IP-based, Session-based
WAN Active on Demand Link Failure, Traffic Threshold
Connection Detection ARP, Ping
WAN Data Budget
Dynamic DNS
DrayDDNS
LAN Management
VLAN 802.1q Tag-based, Port-based
Max. Number of VLAN 16
DHCP Server Multiple IP Subnet, Custom DHCP Options, Bind-IP-to-MAC
LAN IP Alias
Wired 802.1x Authentication
Port Mirroring
Local DNS Server
Conditional DNS Forwarding
Hotspot Web Portal
Hotspot Authentication Click-Through, Social Login, SMS PIN, Voucher PIN, RADIUS, External Portal Server
Networking
Routing IPv4 Static Routing, IPv6 Static Routing, Inter-VLAN Routing, RIP, BGP
Policy-based Routing Protocol, IP Address, Port, Domain, Country
High Availability
DNS Security (DNSSEC)
Multicast IGMP Proxy, IGMP Snooping & Fast Leave, Bonjour
Local RADIUS server
SMB File Sharing (Requires external storage)
VPN
LAN-to-LAN
Teleworker-to-LAN
Protocols PPTP, L2TP, IPsec, L2TP over IPsec, SSL, GRE, IKEv2, IKEv2-EAP, IPsec XAuth, OpenVPN
User Authentication Local, RADIUS, LDAP, TACACS+, mOTP
IKE Authentication Pre-Shared Key, X.509
IPsec Authentication SHA-1, SHA-256, MD5
Encryption MPPE, DES, 3DES, AES
VPN Trunk (Redundancy) Load Balancing, Failover
Single-Armed VPN
NAT-Traversal (NAT-T)
Firewall & Content Filtering
NAT Port Redirection, Open Ports, Port Triggering, DMZ Host, UPnP
ALG (Application Layer Gateway) SIP, RTSP, FTP, H.323
VPN Pass-Through PPTP, L2TP, IPsec
IP-based Firewall Policy
Content Filtering Application, URL, DNS Keyword, Web Features, Web Category* (*: subscription required)
DoS Attack Defense
Spoofing Defense
Bandwidth Management
IP-based Bandwidth Limit
IP-based Session Limit
QoS (Quality of Service) TOS, DSCP, 802.1p, IP Address, Port, Application
VoIP Prioritization
Wireless LAN
Number of SSID 4 per radio band
Security WEP, WPA, WPA2, WPS
Authentication Pre-Shared Key, 802.1X
WDS Bridge, Repeater
Access Control Access List, Client Isolation, Hide SSID, Wi-Fi Scheduling
Airtime Fairness
Band Steering
MU-MIMO
TxBF
WMM
VoIP Gateway
Protocol SIP, RTP/RTCP, ZRTP
SIP Registrars 12
Dial Plan Phone Book, Digit Map, Call Barring, Regional
Call Features Call Waiting, Call Transfer, Scheduled DND, Hotline
Voice Codec G.711 A/u law, G.723.1, G.726, G.729 A/B
Caller ID FSK_ETSI, FSK_BELLCORE, DTMF
Management
Local Service HTTP, HTTPS, Telnet, SSH, TR-069, FTP, SNMP
Config File Export & Import
Config File Compatibility Vigor2925
Firmware Upgrade TFTP, HTTP, TR-069
2-Level Administration Privilege
Access Control Access List, Brute Force Protection
Syslog
Notification Alert SMS, E-mail
SNMP v1, v2c, v3
Managed by VigorACS
Central VPN Management 8 VPN
Central AP Management 20 VigorAP
Central Switch Management 10 VigorSwitch
Physical
Power Supply DC 12V @ 1.5-2A
Max. Power Consumption 29 watts (Vac model)
Dimension 241mm x 166mm x 46mm
Weight 660g (Vac model)
Operating Temperature 0 to 45°C
Storage Temperature -25 to 70°C
Operating Humidity (non-condensing) 10 to 90%
Certificate CE CE

All specifications are subject to change without notice.
